NSS-2400
![$gallery[0]['title']](https://www.vikingenterprisesolutions.com/wp-content/uploads/NSS2400_img1.png)




2U 370TB Hybrid Edge and CDN Platform
The Viking Enterprise Solutions (VES) NSS-2400 is Intel Xeon Scalable (Intel® Xeon 81xx/61xx/51xx/41xx/31xx series) based system which offers up to 370TB of capacity with spinning LFF drives and SFF SSDs. It is designed to fit in a 2 post or 4 post rack, it can be deployed at edge points of the network for minimizing network load. The system operates in environment of up to 40°C. With it’s exceptional thermal management, the platform is highly reliable. NSS-2400 supports AC and DC redundant supplies for maximum flexibility. It can operate indefinitely with a fail fan minimizing service. A simple LCD panel with four button (including power and reset) allows basic functionality without any KVM connection.
Features
- Exceptional thermal management and drive rotation vibration mitigation
- Highly reliable platform
- Can operate indefinitely with a fail fan minimizing service
2U Rackmount Enclosure | AC Power | Monitoring & Reporting | Safety Standards | Environment Protection | Drive Configuration | Ethernet Connectivity | Compute |
---|---|---|---|---|---|---|---|
Dimensions: 29” L X 17.5” W X 3.5” H | Input Voltage: 100-240V AC 50/60 Hz | 1GbE data center connection for management | IEC/EN UL/CSA 60950-1 2nd Edition | RoHS & WEEE compliant | Single NVMe M.2 SSD (2280/2210) | Dual port 100GbE PCIe card + Dual port 25GbE PCIe card | Up to 1TB ECC 3DS LRDIMM, Up to 512GB ECC LRDIMM, Up to 256GB ECC RDIMM |
Weight for VES NSS-2340: 85 LBS | DC Input: 48V-60V DC 20A MAX | NEBS Level 1 Compliant | 2 x 1/10GbE, 5 x USB 3.0, 6 x USB 2.0, 1 x VGA, 1 x TPM header | ||||
Optional 1 x8 PCIe Gen 3 half-height, half-length expansion card |
