VSS2249 PRODUCT FAMILY
Our 2U, 24 U.2 drive family of products consists of High-Availability and High-Performance solutions. Each of the storage server systems are supported with the latest AMD CPUs, with single CPU, dual motherboard configurations. Each system supports either dual port or single port U.2 NVMe PCIe Gen 4 drives and various PCIe Gen 4 I/O configurations.
| VSS2249R | VSS2249RQ | VSS2249P | |
| Enclosure | 2U High Availability, 24 Dual Port U.2 PCIe v4 Drives | 2U High Availability, 24 Dual Port U.2 PCIe v4 Drives | 2U Dual Node, 24 Single Port U.2 PCIe v4 Drives |
| PCIe Slots | 2 x16, HH/HL, 1 x16, OCP v3 | 4 x16, HH/HL | 2 x16, HH/HL, 1 x16,OCP v3 |
| NTB | x8 PCIe 3.0 | x4 PCIe 3.0 | – |
| Server Canister | Each storage server accesses all 24 drives | Each storage server accesses all 24 drives | Each storage server accesses only half the drives |
| Server | Single AMD Rome/Milan CPU, 8 DDR4 DIMM Slots | Single AMD Rome/Milan CPU, 8 DDR4 DIMM Slots | Single AMD Rome/Milan CPU, 8 DDR4 DIMM Slots |
| Management Network | 1GbE – Management Port | 2x10GbE – Management Ports | 1Gbe – Management port |
